Difference between medium frequency induction furnace and high frequency induction furnace

Time:2021-03-24   Nums:1329

Induction heating of medium frequency furnace: the current frequency is 500-10000 Hz (Hz), and various metals of 5kg-60 tons are melted, which has fast speed and high efficiency. Features: large volume, mature technology, high output power and small failure rate. The effective hardening depth is 2-10 mm (mm), which is mainly used for parts requiring deeper hardening layer, such as medium modulus gear, large modulus gear, shaft with larger diameter, etc.

It's the thickness that makes a difference

Induction heating of high frequency furnace: the current frequency is 100-500 kHz (kilohertz), suitable for smelting 1-5kg precious metals, with fast speed, low price, small volume, small and effective hardening depth of 0.5-2 mm (mm), mainly used for medium and small parts requiring thin hardening layer, such as small module gear, small and medium-sized shaft.

Yiphee Electric Furnace Co.,Ltd specializes in producing induction smelting furnace.Tel(WhatsApp):+86-13450756789, yiphee@yiphee.cn
